Safety Belt Continuous Dyeing Machine
Safety belt webbing is not a normal decorative strap. It is a safety-critical textile: the shade, width, surface and elongation have to stay consistent along the roll. A batch dyeing machine or a narrow ribbon line is not the right process for this product.
This is a safety belt continuous dyeing machine for automotive safety belt webbing and seat belt webbing. It is configured as a complete continuous line, from feed-in to take-off, with washing and chemical finishing.
What It Dyes
- Automotive safety belt webbing
- Seat belt webbing
- Safety harness webbing
The line is focused on safety belt and seat belt webbing. It is not a luggage strap line and not a webbing sling line.
Complete Continuous Line
The line runs continuously through:
1. Feed-in
2. Pre-washing
3. Pre-dryer
4. Dyeing padder
5. IR pre-drying
6. Steam box
7. Washing tank
8. Chemical padding — two chemical tanks
9. Drying and finishing unit
10. Cooling
11. Take-off
The steam box, washing tank and double chemical tanks are part of the line. The exact configuration is confirmed against your webbing width, thickness, and output.
Working Width, Speed and Strap Count
- Working widths: 200 mm, 400 mm and 600 mm
- Line speed: 15, 30 or 40 m/min, depending on configuration
- Strap count: 6, 10 or 20 straps, depending on working width and strap width
- Maximum webbing thickness: below 1.5 mm
- Control: manual or PLC
The number of straps varies by customer. A wider line can run more narrow straps; a narrower line runs fewer. We confirm the layout from your webbing width and daily output.
Heat Setting and Heating
The line uses a steam box for heat setting, with a working length of 45–80 m depending on configuration.
Heating options are electric, GLP, or steam, selected for your factory utilities and dyeing process.
Washing and Chemical Finishing
After heat setting, the line runs through a washing tank and two chemical tanks. This allows washing and chemical finishing in the same continuous line, before drying and cooling.
The exact chemical finishing sequence is confirmed with your webbing specification and dye process.
Specifications
- Application: automotive safety belt webbing, seat belt webbing, safety harness webbing
- Working width: 200 / 400 / 600 mm
- Line speed: 15 / 30 / 40 m/min
- Strap count: 6 / 10 / 20, depending on width
- Maximum thickness: below 1.5 mm
- Steam box length: 45–80 m, depending on configuration
- Process: feed-in → pre-washing → pre-dryer → dyeing padder → IR pre-drying → steam box → washing tank → two chemical tanks → drying and finishing → cooling → take-off
- Heating: electric / GLP / steam
- Control: manual or PLC
- Construction: stainless steel
- Warranty: 1 year
- Certification: CE
- Installation: free on-site installation and operator training
Final power supply, dimensions, and weight are confirmed with the quotation. The line is built around your webbing width, strap count, and output.
Who It Is For
This line is for automotive safety belt and seat belt webbing producers who need continuous dyeing, washing, and chemical finishing in one line.
It is not a luggage strap line and not a webbing sling line. For luggage straps, use the luggage strap continuous dyeing machine. For webbing slings, use the webbing sling pigment dyeing machine.
Warranty, CE and Installation
The line comes with a 1-year warranty and CE certification. Free on-site installation and operator training are included.
Online support is available for daily operation and technical questions.
Frequently Asked Questions
Q: What webbing can this line dye?
A: Automotive safety belt webbing, seat belt webbing, and safety harness webbing.
Q: What working widths are available?
A: 200 mm, 400 mm, and 600 mm.
Q: What is the line speed?
A: 15, 30, or 40 m/min, depending on configuration. Actual speed depends on webbing width, thickness, shade, and drying.
Q: How many straps can it run at once?
A: 6, 10, or 20 straps, depending on working width and strap width. The layout is confirmed from your product.
Q: What is the maximum webbing thickness?
A: Below 1.5 mm.
Q: What is the process flow?
A: Feed-in → pre-washing → pre-dryer → dyeing padder → IR pre-drying → steam box → washing tank → two chemical tanks → drying and finishing → cooling → take-off.
Q: Does it include washing and chemical finishing?
A: Yes. The line includes a washing tank and two chemical tanks.
Q: How is the line heated?
A: Electric, GLP, or steam, selected for your factory utilities and process.
Q: Is it manual or PLC controlled?
A: Both are available. Manual and PLC control are optional configurations.
Q: Does the machine guarantee automotive safety belt standards?
A: The machine is CE certified, but safety belt performance depends on your webbing, dye, chemical process, and test standard. We confirm the line configuration with your sample and specification; we do not claim the finished belt meets a specific automotive standard without testing.
Q: Can it dye luggage straps or webbing slings?
A: Not on this page. Use the luggage strap continuous dyeing machine or the webbing sling pigment dyeing machine.
Q: Is installation included?
A: Yes. Free on-site installation and operator training are included, with online support.
Q: What is the warranty?
A: One-year warranty, CE certified.
Q: Can I send a sample?
A: Yes. Send your safety belt webbing sample, width, thickness, and target shade so we can confirm the line configuration.
Send Your Webbing Sample
Send your safety belt webbing sample, width, thickness, and target shade. We will confirm the working width, strap count, steam box length, and chemical finishing configuration.
